FEYANA Two-Component Thermally Conductive Epoxy Potting, 0.7–2.1 W/mK
FEYANA JD/JE/JA two-component thermally conductive epoxy: 0.7–2.1 W/mK, Tg up to 207°C, room temperature or heat cure, potting transformers, inductors, modules.
FEYANA two-component thermally conductive epoxy is used for potting and bonding, protecting components from moisture, vibration and chemicals while dissipating heat. Room-temperature-cure and heat-cure high-Tg grades are available.
Specifications
| Brand | FEYANA |
|---|---|
| Chemistry | Two-component epoxy |
| Thermal conductivity | 0.7 – 2.1 W/mK |
| Mix ratio | 1:1, 2:1, 5:1, 10:1, 100:8 by grade |
Product range
| Product | Color | Viscosity (cps) | Mix ratio A:B | Pot life 25°C (hr) | Full cure (heat / room temp.) | Tg (°C) | Hardness Shore | Thermal conductivity (W/mK) | Operating temp. (°C) |
|---|---|---|---|---|---|---|---|---|---|
| JD867-2AB | White | A: 40,000~80,000; B: <100 | 10:1 | 4 | 80°C×120 min / 5~7 days | 45 | D88 | 0.8 | -40~100 |
| JD173-2AB | Gray | A: 170,000~280,000; B: 230,000~400,000 | 2:1 | 1 | 80°C×60 min / 5~7 days | 44 | D88 | 2 | -40~100 |
| JD716-5AB | Black | A: 324,000; B: <200 | 10:1 | 3 | 80°C×60 min / 5~7 days | 40 | D78 | 0.7 | -40~100 |
| JA293-49AB | Black | A: 70,000~140,000; B: ≤100 | 100:8 | 6 | 80°C×2 hr / 5~7 days | 41 | D84 | 0.8 | -40~100 |
| JD716-20AB | Black | A: 180,000~220,000; B: <200 | 10:1 | 2 | 70°C×180 min / 5~7 days | 72 | D87 | 1 | -40~180 |
| JE280AB | Black | A: 75,000~150,000; B: 3,000~9,000 | 1:1 | 4 | 140°C×2 hr | 140 | D89 | 1 | -40~180 |
| JE335AB | Black | A: 150,000~300,000; B: ≤100 | 5:1 | 4 | 160°C×2 hr | 150 | D90 | 1 | -40~200 |
| JD113AB | Black | A: 35,000~52,000; B: 12,000~18,000 | 2:1 | 3 | 80°C×60 min / 5~7 days | 18 | A71 | 1.3 | -40~100 |
| JE136-5AB | Gray | A: 125,000~250,000; B: 15,000~45,000 | 1:1 | 4 | 120°C×3 hr | 130 | D91 | 1.3 | -40~200 |
| JA293-29AB | Gray | A: 12,000~30,000; B: 20,000~32,000 | 2:1 | 1 | 80°C×60 min / 5~7 days | 36 | D88 | 1.5 | -40~100 |
| JE136-18AB | Gray | A: 50,000; B: 20,000 | 1:1 | 4 | 130°C×2 hr | 207 | D91 | 2.1 | -40~200 |
Typical values from FEYANA technical data for selection reference only; please test on your actual substrates before mass production. Viscosity, colour, cure speed and packaging can be customised on request.
Key features
- Mechanical, moisture and chemical protection
- High Tg up to 207°C
- Wide choice of mix ratio, viscosity and hardness
Applications
- Potting transformers, inductors, motors
- Power modules, power supplies
- Sensors and automotive components
Technical support and quotation
Send FEYANA your substrates, operating conditions (temperature, environment), thermal conductivity, flame-retardancy and hardness requirements, application method (manual, cartridge gun, dispensing machine) and volume for product recommendation, samples and a quotation. We supply from Vietnam across Southeast Asia.
- WhatsApp / Phone: +84 988 641 591
- Email: sales.00@feyana.com
