GKN Cardan Shaft Series 880 with 2C – 10C Connections
GKN Series 880 cardan shafts with 2C–10C connections: TK 0.8–26 kNm, flange diameter 87–226 mm, Rilsan coated, for construction machinery and railway.
Series 880 is the GKN cardan shaft range with 2C to 10C cross connections common on construction machinery, special vehicles and railway vehicles. Rilsan-coated slip sections keep maintenance low.
Specifications
| Brand | GKN |
|---|---|
| Torque TK | 0.8 – 26 kNm |
| Flange diameter | 87 – 226 mm |
| Connections | 2C, 4C, 5C, 6C, 7C, 8C, 8.5C, 9C, 10C |
| Regreasing interval | 3 months |
| Size | Connection | TK (kNm) |
|---|---|---|
| 880.02 | 2C | 0.8 |
| 880.04 | 4C | 1.5 |
| 880.05 | 5C | 2.65 |
| 880.06 | 6C | 3.4 |
| 880.07 | 7C | 5.7 |
| 880.08 | 8C | 8.5 |
| 880.85 | 8.5C | 14 |
| 880.09 | 9C | 18.6 |
| 880.10 | 10C | 26 |
GKN cardan shaft range: max static torque up to 70,000 Nm, flange diameters 58 – 285 mm, shaft lengths up to 6,000 mm; ATEX conformity certificates category 2 and 3 available (per manufacturer).
Features
- Industry-standard cross connections
- Rilsan coated, low maintenance
- 9 sizes
Applications
- Construction machinery
- Railway vehicles
- Industrial machinery
Request a quote
Prices depend on model, size, connection type and quantity. Send FEYANA the part number or nameplate photo, drawing or mating dimensions, power, speed and operating conditions for correct selection and a fast quotation. We supply from Vietnam across Southeast Asia.
- WhatsApp / Phone: +84 988 641 591
- Email: sales.00@feyana.com
